Project Case
Chemical engineering industry
Pesticide special dryer (Zhejiang Xinhecheng Co., Ltd.)
Application client：Zhejiang Xinhecheng Co., Ltd.Selected products：：Centrifugal spray dryer
Materiel:： Pesticide
Detailed description
principle:
After filtering and heating, the air enters the air distributor at the top of the dryer, and the hot air enters the drying chamber evenly in a spiral shape. The feed liquid is sprayed into a very fine mist-like liquid bead by the high-speed centrifugal atomizer (rotation) at the top of the tower body, and it is in parallel flow contact with hot air, and can be dried into a finished product in a very short time. The finished product is continuously output from the bottom of the drying tower and the cyclone separator, and the exhaust gas is evacuated by the fan.
Features:
● The drying speed is fast, the surface area of the material liquid is greatly increased after being atomized. In the hot air flow, 95% -98% of water can be evaporated in an instant, and the drying time is only a few seconds, which is especially suitable for heat-sensitive materials. dry.
● The product has good uniformity, fluidity and solubility, high purity and good quality.
● Simplified production process and convenient operation and control. For liquids with a moisture content of 40-60% (special materials up to 90%) can be dried into powder products at a time, without crushing and screening after drying, reducing the production process and improving product purity. The product particle size, bulk density, and moisture can be adjusted within a certain range by changing the operating conditions, which is convenient for control and management.
Technical number:
| Project / parameter | Model: LPG | |||||
| 5 | 25 | 50 | 100 | 150 | 200-2000 | |
| Inlet temperature ℃ | 140 ~ 350 automatic control | |||||
| Outlet temperature ℃ | ~ 80-90 | |||||
| Maximum evaporation of water kg / h | 5 | 25 | 50 | 100 | 150 | 200-2000 |
| Rotating form of centrifugal spray head | Compressed air transmission | Mechanical transmission | ||||
| Speed (rpm) | 25000 | 18000 | 18000 | 18000 | 15000 | 8000-15000 |
| Spray disc diameter (mm) | 50 | 100 | 120 | 140 | 150 | 180-340 |
| Heat source | Electricity | Electricity + steam | Electricity + steam, fuel oil, gas | Solved by the user | ||
| Electric heating maximum power KW | 9 | 36 | 63 | 81 | 99 | |
| Length × width × height (m) | 1.8 × 0.93 × 2.2 | 3 × 2.7 × 4.26 | 3.7 × 3.2 × 5.1 | 4.6 × 4.2 × 6 | 5.5 × 4.5 × 7 | According to the specific situation |
| Dry powder recovery rate% | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 |
Note: Some parameters are adjusted according to different materials during design, subject to the design.
Equipment installation site pictures:
